Chlorine Gas Detector for OSHA | USA NIST Calibration

Save 45%

Price:
Sale price$545.00 Regular price$995.00
Stock:
In stock (43 units), ready to be shipped

Brand: FORENSICS DETECTORS
Model: FD-90A-Cl2-LOW
User Manual (PDF): EN | DE | FR | ES | IT |
Insights: Read the Expert Guide

Features:

  • ⚛️ ACCURATE: OSHA low-level chlorine (Cl2) gas detector, 0 - 10 ppm with 0.01 ppm resolution.
  • 🚄 DETECT: Electrochemical NANO-GAS sensor.
  • 🎆 ALARMS: Adjustable audio, visual, and vibration alarms.
  • 💪 STRONG: Shockproof, water-resistant, dustproof, and explosion-proof.
  • 🕵️ TRUSTWORTHY: 1-year limited warranty. Arrives with a signed and dated calibration certificate.

Details: The low-level professional chlorine (Cl₂) gas detector offers a 0–10 ppm range with 0.01 ppm resolution, making it ideal for low-level OSHA compliance alarming. Factory-calibrated and ready to use, it continuously monitors chlorine gas concentrations in industrial environments where the gas is commonly used for water treatment, disinfection, and chemical manufacturing. While chlorine is highly effective as a sanitizing and bleaching agent, improper exposure poses serious risks — including severe respiratory irritation, pulmonary damage, and potential chemical hazards. This advanced detector provides reliable, real-time protection, ensuring worker safety and regulatory compliance wherever chlorine gas is present. NIOSH exposure limits are set with a maximum ceiling (15-minute exposure) of 0.5 ppm. OSHA permissible exposure level is set at 1 ppm. If you don't need such high resolution, the FD-600-CL2 is an alternative with a built-in pump, making it the best candidate for point sampling and leak detection.

Included: Chlorine gas detector, belt clip, sling, user manual, USB charging cable, calibration cover, and certified calibration certificate.

Calibration Options:
1. Professional Calibration: Serviced by Forensics
2. Calibration Guide: Calibrate It Yourself

Calibration Kit (needed to calibrate yourself - sold separately):
None available. Must be calibrated by Forensics Detectors via our Gas Detector Calibration Service. However, a bump tester is available.

Accessories (sold separately):
Pump and Probe
Gas Detector Hard Case
Gas Detector Pouch
Gas Detector Stand
Sensor Replacement (email us)

Specifications

Chlorine (Cl2) Detection: 0 - 10 ppm with 0.01 ppm resolution
Gas Sensor Type: Electrochemical Gas Sensor
Gas Sensor Life: 2 - 3 years
Sampling Type: Diffusive (no pump) | Add-on Pump
Operating Pressure: 1.0 bar nominal (range: 0.8 to 1.2 bar)
Recommended Calibration Period: 12 months
Datalogging: No
Analog Signal Output: No

Error: ≤ ± 5% F.S.
Response Time: < 30 sec
Indicators: LCD indicates the time, concentration, internal electronics temperature tracking, and battery level
Store / Operating Temp: 0 to 122°F (−18 to 50°C)
Store / Operating Humidity: <95% RH
Display Type: Backlit monochrome LCD
Battery: DC 3.7V Li-battery 1500 mAh
Explosion-Proof Grade: ATEX certified Ex ia IIC T4 Ga (📋 PDF)
Protection Category: IP54
Weight: 5.0 oz (140 grams)
Dimensions: 4.3 × 2.3 × 1.7 inches (10.9 × 5.8 × 4.3 cm)
Housing Material: ABS Plastic
Charge Time: 3 hours

Operating Time: > 24 hours
Alarm: LED, Buzzer, and Vibration
Audible Buzzer Alarm: ≥ 85 dB @ 1 meter
Recommended USB Power Supply: 5V / 1A minimum (USB-A)
Calibration Location (USA): Los Angeles, California, USA
Calibration Standard (USA): USA NIST Traceable Gas Source
Calibration Location (Europe): Athens, Greece
Calibration Standard (Europe): European NPL Traceable Gas Source
