Nitrogen Dioxide Detector | USA NIST Calibration

Save 59%

Price:
Sale price$365.00 Regular price$895.00
Stock:
In stock (109 units), ready to be shipped

Brand: FORENSICS DETECTORS
Model: FD-90A-NO2
User Manual (PDF):
EN | DE | FR | ES | IT |
Insights: Read the Expert Guide

Features:

  • ⚛️ DETECT: Single-gas detector for nitrogen dioxide NO2 gas, 0 - 20 ppm with 0.1 ppm resolution. Electrochemical sensor.
  • ⚛️ DETECT: Electrochemical NANO-GAS sensor.
  • 🎆 ALARMS: Adjustable audio, visual, and vibration alarms.
  • 💪 STRONG: Shockproof, water-resistant, dustproof, and explosion-proof.
  • 🕵️ TRUSTWORTHY: 1-year limited warranty. Arrives with a signed and dated calibration certificate.

Details: The nitrogen dioxide (NO2) gas detector by FORENSICS has the most advanced features and functions for industrial applications, including an advanced electrochemical sensor. Nitrogen dioxide (NO2) is part of a group of highly reactive gases known as nitrogen oxides (NOx). NO2 is used as the indicator for the larger group of nitrogen oxides. Nitrogen dioxide primarily gets in the air from the burning of fuel. NO2 is formed from emissions from cars, trucks, buses, power plants, and off-road equipment. OSHA workplace exposure limits are set at 5 ppm over any period of time. The NIOSH REL is set at 1 ppm as a 15-minute short-term limit. ACGIH exposure limit is 3 ppm over 8 hours and/or 5 ppm short-term exposure. For those requiring point sampling or NO2 leak detection, you will need a NO2 analyzer with a built-in pump analyzer variation; in this case, we recommend our FD-600-NO2. Also, for those requiring a NOx analyzer, see our FD-600-NOx.

Included: Nitrogen Dioxide gas detector, belt clip, sling, user manual, USB charging cable, calibration cover, and certified calibration certificate.

Calibration Options:
1. Professional Calibration: Serviced by Forensics
2. Calibration Guide: Calibrate It Yourself

Calibration Kit (needed to calibrate yourself - sold separately):
Calibration Gas (NO2)
Calibration Gas Regulator (C10)
Tubing

Accessories (sold separately):
Pump and Probe
Gas Detector Hard Case
Gas Detector Pouch
Gas Detector Stand
Gas Sensor Replacement (NO2)

Specifications

Nitrogen Dioxide (NO2) Detection: 0 - 20 ppm with 0.1 ppm resolution
Gas Sensor Type: Electrochemical Gas Sensor
Gas Sensor Life: 2 - 3 years
Sampling Type: Diffusive (no pump) | Add-on Pump
Operating Pressure: 1.0 bar nominal (range: 0.8 to 1.2 bar)
Recommended Calibration Period: 12 months
Datalogging: No
Analog Signal Output: No

Error: ≤ ± 5% F.S.
Response Time: < 30 sec
Indicators: LCD indicates the time, concentration, internal electronics temperature tracking, and battery level
Store / Operating Temp: 0 to 122°F (−18 to 50°C)
Store / Operating Humidity: <95% RH
Display Type: Backlit monochrome LCD
Battery: DC 3.7V Li-battery 1500 mAh
Explosion-Proof Grade: ATEX certified Ex ia IIC T4 Ga (📋 PDF)
Protection Category: IP54
Weight: 5.0 oz (140 grams)
Dimensions: 4.3 × 2.3 × 1.7 inches (10.9 × 5.8 × 4.3 cm)
Housing Material: ABS Plastic
Charge Time: 3 hours

Operating Time: > 24 hours
Alarm: LED, Buzzer, and Vibration
Audible Buzzer Alarm: ≥ 85 dB @ 1 meter
Recommended USB Power Supply: 5V / 1A minimum (USB-A)
Calibration Location (USA): Los Angeles, California, USA
Calibration Standard (USA): USA NIST Traceable Gas Source
Calibration Location (Europe): Athens, Greece
Calibration Standard (Europe): European NPL Traceable Gas Source
