Nitrogen Dioxide Sensor (NO2) | 0 - 20 ppm |

Model: FD-NO2-SENSOR
Datasheet: Click Here PDF
Availability: 3 week lead time
Compatible: FD-90A-NO2

Features

• ⚛️ High precision and long life (2 years)
• 🚄 Fast response speed, fast return to zero (T< 30 seconds)
• 🔋 Low power consumption, high sensitivity
• 🔬Wide linear range, strong anti-interference ability
• 💪 Excellent repeatability and stability

Description

These are generic NO2 sensors used as the pin-to-pin replacement of the standard 4-series electrochemical sensors. It is used throughout many gas detector brands and is an excellent NO2 gas sensor replacement element.

Our NO2 nitrogen dioxide sensor utilizes an advanced electrolytic mechanism where nitrogen dioxide and oxygen undergo redox reactions on specialized electrodes. This process generates an electrical current directly proportional to the nitrogen dioxide concentration. By precisely measuring the test current's magnitude, the sensor can accurately determine and quantify the presence of nitrogen dioxide in various environmental monitoring applications.

Our NO2 detection technologies play a critical role in diverse industrial and environmental monitoring applications. From industrial sites and mining operations to smart city infrastructure and environmental protection initiatives, NO2 detectors provide essential insights into gas concentration levels. These advanced sensing systems enable comprehensive monitoring, early warning mechanisms, and precise measurement of nitrogen dioxide, supporting safety, environmental health, and regulatory compliance across multiple sectors.

Instructions

• Once replaced and installed in your gas detector or analyzer, please let it sit for 24 hours so the sensor can stabilize to your environment. This step is very important.
• Then undertake the appropriate zero and calibration for your specific gas detector. See your gas detector manufacturer's specific instructions.
• Once calibrated, your gas analyzer will be ready for use.

Specifications

Detection Principle	Electrochemical Tri-electrode
Detection Gas	NO2
Detection Range	0-20 PPM
Maximum Load Concentration	200 PPM
Output Signal	-600±150 nA/PPM
Zero Drift	0~1 PPM
Resolution	0.1 PPM
Response Time	<30s
Bias Voltage	0
Load Resistance	5~30Ω
Working Temperature	-30℃-50℃
Working Humidity	15%RH to 90%RH (no condensation)
Repeatability	<±2% output signal
Long-term Stability	<2% signal/month
Linearity	100 PPM
Work Pressure	90 to 110 kPa
Shelf Life	12 months after delivery
Service Life	2 years

Cross-Sensitivity Data

Interfering Gas	Used Gas Concentration (ppm)	Value Displayed (ppm NO2)
CO	400	0
SO2	5	<3
H2S	25	<1
CL2	11	-2
NO	30	0
C2H4	20	0
